ISW Order Entry Sub Panels
Use the sub-panels to create advanced orders and apply order attributes. Use the Destination list to select an algo exchange and define an algo order.
To Use the Sub Panels
-
Click the sub-panels drop down to display the list of available attributes and advanced order types.
Note: This menu is context-sensitive, so that only the order types that are valid for the order parameters you have defined will be shown. For example, if your order type is Stop, the Scale sub-panel will not be shown in the drop-down list for that order since the Scale attributes can only be applied to Limit and Relative orders.
-
Check the order attributes you want to apply to open the sub-panel(s) for that order type.
-
Enter values for the selected order type.
To Enter an Algo Order
-
From the DEST drop-down list, select an algo destination under the Algorithms section.
-
In the new algo-specific panel, enter algo parameters.
See the TWS Users’ Guide topics for details on setting up algo orders:
-
IBAlgos
Learn About Integrated Stock Window in Trader Workstation at IBKR Campus
